Wholesale SEI 8KW 10KW 12KW Split Phase Hybrid Inverter Manufacturer

SEI 8KW/10KW/12KW Split Phase Hybrid Inverters are designed for high-performance residential and light commercial energy systems. Supporting 120V/240V split-phase output, these inverters provide flexible power distribution for both standard household appliances and high-power equipment. With intelligent hybrid energy management, seamless battery integration, and efficient solar utilization, the SEI Series offers reliable backup power and optimized energy independence for modern solar applications.

Product Series: SEI Split Phase Hybrid Inverter
Power Range: 8KW / 10KW / 12KW
System Type: Hybrid Solar Energy System
Battery Type: Lead-acid / Li-ion / User-defined
Rated Output Voltage: 120/240Vac, single-phase / split-phase / three-phase(parallel)
DownloadInquire

Note: Please read the safety and installation manual before using the product. We reserve the right of finalinterpretation.

The specifications in this datasheet are subject to change without notice.

Features

Efficiency

  • Advanced MPPT technology with up to 99.9% efficiency
  • Up to 22A*2 PV input current

Reliable

  • Outputs high quality pure sine wave AC power
  • With IP65 protection degree

Safety

  • With software and hardware security protection
  • Multiple safety approvals

User-Friendly

  • Industrial design with a modern aesthetic look
  • Easy to install and simple to use

All-in-One

  • Up to 200A charging current
  • Support Li-ion battery BMS communication

Intelligent

  • Exclusive Li-ion battery BMS dual activation
  • Time-slot function to save cost with peak-valley

Basic Parameters

MODELSEI-8K-UPSEI-10K-UPSEI-12K-UP
Rated Output Power8,800W10,000W12,000W
Max. Peak Power17,600VA20,000VA24,000VA
Rated Output Voltage120/240Vac, single-phase / split-phase / three-phase(parallel)
Load Capacity of Motors5HP6HP
Rated AC Frequency50/60Hz
Battery TypeLead-acid / Li-ion / User-defined
Rated Battery Voltage48V
Max. PV Charging Current200A
Max. Mains Charging Current120A
Max. Alternator Charging Current60A
Max. Hybrid Charging Current200A
Num. of MPPT2
Max. PV Array Power5,500W + 5,500W6,600W + 6,600W
Max. Input Current22A + 22A
Max. Open-circuit Voltage500Vdc + 500Vdc
MPPT Operating Voltage Range125~425Vdc
Input Voltage Range90~140Vac
Frequency Range50/60Hz
Num. of Parallel1~6 units
Dimensions750×440×240mm
Weight42kg
Protection DegreeIP65
Operating Temperature Range-25~60℃, >45℃ derated
Cooling MethodIntelligent air-cooling
Warranty5 years
Embedded InterfacesRS485 / CAN / USB / Dry contact
External Modules (optional)Wi-Fi / GPRS
Safety CertificationIEC62109-1, IEC62109-2
RoHSYes

FAQs

1. Which SEI model is best for medium to large residential systems?

The 8KW model is suitable for medium-sized homes, the 10KW model fits higher household energy demand, while the 12KW model is ideal for large residences or light commercial hybrid solar systems.

2. Can the 12KW inverter support multiple high-power appliances at the same time?

Yes. The SEI 12KW model is designed to handle larger electrical loads simultaneously, including air conditioners, pumps, ovens, and other high-consumption equipment.

3.What are the advantages of choosing a 10KW hybrid inverter?

A 10KW hybrid inverter provides a balanced combination of power capacity, battery storage compatibility, and solar energy utilization, making it a popular choice for advanced home energy systems.

4. Are 8KW, 10KW, and 12KW models suitable for battery backup applications?

Yes. All three models support hybrid energy storage systems and can provide reliable backup power during grid outages or unstable power conditions.

5. How do I decide between 8KW, 10KW, and 12KW?

The selection depends on your total electricity consumption, number of appliances, battery capacity, and future expansion plans. Larger systems with higher daily loads generally benefit more from 10KW or 12KW models.
